Max. battery working time AP 300.0 P | 20 min |
Min. battery working time AP 300.0 P | 20 min |
Max. battery working time AP 500 S | 20 min |
Min. battery working time AP 500 S | 20 min |
Max. cuts per battery charge AP 500 S | 320 pcs |
Bar length | 20 in |
Power consumption | 3.50 kW |
Device weight without battery | 9.8 lb |
System weight without battery | 13.4 lb |
Device length with bumper spike | 19.4 in |
Power | 3.9 BHP |
Power | 3.886 BHP |
Max. voltage | 40 V |
Rated voltage | 36 V |
Groove width | 63 in |
Recommended battery | AP 300.0 P |
Saw chain pitch | .325" |
Vibration level left | 8.5 ft/s² |
Vibration level right | 9.2 ft/s² |
Cordless power system | ALLPRO/AP |
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Suspendisse varius enim in eros elementum tristique. Duis cursus, mi quis viverra ornare, eros dolor interdum nulla, ut commodo diam libero vitae erat. Aenean faucibus nibh et justo cursus id rutrum lorem imperdiet. Nunc ut sem vitae risus tristique posuere.
OIL CONSUMPTION BASED ON NEED. The controlled-delivery oil pump reduces your chainsaw’s oil consumption by up to 50%. To use it, simply select the E position. For very long cutting attachments or very dry wood, an additional oil volume can be set by the user.
QUICK AND EASY TO USE. Thanks to the bayonet closure, you can open and close the tool-free fuel cap in just a few simple steps.
SPLASHWATER PROTECTION. The IPX protection classes define the moisture protection of electrical or electronic devices. The moisture protection test is defined in different stages. IPX4 certifies protection against splashwater from all sides.
MAXIMUM PERFORMANCE INCREASE. Thanks to internal intelligent electronics, STIHL power tools and batteries communicate with each other. If the device and battery are equipped with the POWER BOOST function, the battery always provides the maximum possible power for the respective application. In order to ensure optimum battery life, the device temporarily adjusts the power if it is used too intensively.
CONSTANT POWER, REGARDLESS OF BATTERY CHARGE STATUS. With other brands of battery tools, the performance usually decreases during work as the battery discharges. This is not the case with STIHL cordless power tools with CONSTANT POWER. Thanks to the intelligent electronics, your STIHL power tool works with consistently high power.
FOR CONTROL AND MONITORING OF THE OIL SUPPLY. The LED display on the oil sensor informs you about the delivery of chain lubricant. If the LED is red, there is not enough chain oil reaching the chain. When the oil supply is sufficient, the LED is off.
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Suspendisse varius enim in eros elementum tristique. Duis cursus, mi quis viverra ornare, eros dolor interdum nulla, ut commodo diam libero vitae erat. Aenean faucibus nibh et justo cursus id rutrum lorem imperdiet. Nunc ut sem vitae risus tristique posuere.
